- Mixing, pneumatic input, substrate processing, bagging, metal processing, air conveying inlet, sanding electric, casting, cutting, mixing, drilling, severing, cutting, breaking, stone engraving, etc. |
| |
|
 |
| |
|
| FILTER |
The cartridge type filter structure can secure the filtering area and even collect minute dust. |
| Manometer |
It is easy to check the accumulation of the dust in the filter so that replacement timing can be easily checked. |
| Continuous Operation |
The automatic dusting-off during performance of the dust collector makes 24-hour continuous operation possible. |
| FILTER CLEANING |
The compressed air automatically injects the dust attached to the cartridge filter through the blow tube by means of the jet method, and the dusting-off efficiency is high because near by air is sucked in and made to flow backward. |
| TURBO BLOWER |
Suitable for use with high pressure turbo blower or ring blower |
| The Highly Efficient Preprocessing System Mounted |
The embedded filter for the highly efficient preprocessing device (that doesn't exist in other dust collectors) can be used for a long time. |
* Applying for design registration
|
| |
 |
| |
 |
| |
|
 |
| |
 |
| |
|
|
 |
|
